Kia EV6: Tailgate Back Panel

Removal

1.Remove the tailgate back panel (A).

Kia EV6. Tailgate Back Panel

Clip position :

Kia EV6. Tailgate Back Panel

Installation

1.Install in the reverse order of removal.
